標準產線｜1500系列
OM-1500 棧板腳組合機
- 半自動棧板腳組合機。
- 2 名機器操作員
- 12 個棧板腳/分鐘
棧板打釘機
依照你的需求，輕鬆調整
機器運作方式?
腳粒經由輸送帶自動送進，底板則送進卡槽。輸送帶會將腳粒送至釘合位置。 本機會自動將腳粒及底板置於正確位置進行釘合。
可方便調整
使用本機可輕鬆製作各種尺寸的棧板腳。 調整不同變形相當俐落且迅速。在所有Mychrome機器上，只需幾分鐘即可修改棧板腳尺寸及設計的設定。
Mychrome擁有多種可輕鬆連接現有機器的附加機械設備，可建立具更多自動化階段的生產線。連接附加機械後仍可修改棧板的設計和尺寸。
SPECIFICATION MACHINE
| Machine specification | Standard performance |
|---|---|
| Operators | 1 |
| Length | 2,0 m |
| Width | 2,5 m excluding platform ladder |
| Height | 3,6 m |
| Power | Electric: 6 kW, 3x400 V+N, Hydraulic: 15 kW, 3x400 V+N |
| Pneumatic system | 7 bar compressed dried air: 300 L/min |
| Should be filled and controlled | Container for lubricating oil |
| Machine capacity | 12 legs/min |
| Standard equipment | 3 channels with motorized adjustment 3 block stoppers, manually adjustble for blocks position 1 cassette, manually adjusted for board length 1 belt conveyor for block infeed Operators terminal for production control Program for saving nail positioning |
| Nailing system | Electric or hydraulic beam nailing , 1 nail box(9 nails), 9 nailing hammerheads, individual nail picking, nail indication system |
SPECIFICATION MATERIAL
| Matrix material: Blocks | Height | Width |
|---|---|---|
| Material | Solid wood or pressed blocks | |
| Dimension | 70-100 mm | 75-150 mm |
| Matrix material: Leg boards | Minimum | Maximum |
|---|---|---|
| Length | 600 mm | 1600 mm |
| Width | 75 mm | 150 mm |
| Thickness | 16 mm | 28 mm |
| Material: Deck board | Minimum | Maximum |
|---|---|---|
| Length | 600 mm | 1600 mm |
| Width | 75 mm | 150 mm |
| Thickness | 16 mm | 28 mm |
